Kategorija proizvoda: JIC adapteri za hidraulične ugradnje za cijevni priključak fluidne struje
Standard proizvoda: ISO 8434-2, SAE J514.
Materijal: ugljični čelik, nehrđajući čelik ili bakrena legura.
Kraj JIC cijevi do drugog krajnjeg spoja kako slijedi: BSP zaštitna brtva E, G, H tipovi, armatura serije ISO 6149, fitinzi JIS B2351, ISO 11926 i SAE J1926 ORB okovi, DIN 3852 i ISO 1179 okovi, ISO 9974 fitinzi itd.
1JB-OR / WD JIC MUŠKI 74 ° CONE SA O-RING / BSP MALE CAPTIVE SEAL dimenzionalnom shemom kako slijedi:
DIO NE. | NIT | O-PRSTEN zarobljenik | DIMENZIJE | ||||||
E | F | E | F |
| B | L | S1 | ||
1JB-08-04OR / WD | 3/4" X16 | G1 / 4" X19 | 9.5X0.8 | WD-B04 | 16.7 | 12 | 37 | 22 | |
1JB-08-06OR / WD | 3/4" X16 | G3 / 8" X19 | 9.5X0.8 | WD-B06 | 16.7 | 12 | 37,5 | 22 | |
1JB-08OR / WD | 3/4" X16 | G1 / 2" X14 | 9.5X0.8 | WD-B08 | 16.7 | 14 | 43,5 | 27 | |
1JB-08-12OW / WD | 3/4" X16 | G3 / 4" X14 | 9.5X0.8 | WD-B12 | 16.7 | 16 | 45 | 32 | |
1JB-10-06OR / WD | 7/8" X14 | G3 / 8" X19 | 13X1 | WD-B06 | 19.3 | 12 | 41,5 | 24 | |
1JB-10-08OR / WD | 7/8" X14 | G1 / 2" X14 | 13X1 | WD-B08 | 19.3 | 14 | 46,5 | 27 | |
1JB-10-12OR / WD | 7/8" X14 | G3 / 4" X14 | 13X1 | WD-B12 | 19.3 | 16 | 47.5 | 32 | |
1JB-12OR / WD | 1.1 / 16" X12 | G3 / 4" X14 | 17X1 | WD-B12 | 21,9 | 16 | 50 | 32 | |
1JB-12-06OR / WD | 1.1 / 16" X12 | G3 / 8" X19 | 17X1 | WD-B06 | 21,9 | 12 | 46 | 30 | |
1JB-12-08OR / WD | 1.1 / 16" X12 | G1 / 2" X14 | 17X1 | WD-B08 | 21,9 | 14 | 48,5 | 30 | |
1JB-12-16OR / WD | 1.1 / 16" X12 | G1" X11 | 17X1 | WD-B16 | 21,9 | 18 | 56 | 41 | |
1JB-12-20OR / WD | 1.1 / 16" X12 | G1.1 / 4" X11 | 17X1 | WD-B20 | 21,9 | 20 | 60 | 50 | |
1JB-16OR / WD | 1,5 / 16" X12 | G1" X11 | 22X1.5 | WD-B16 | 23.1 | 18 | 57 | 41 | |
1JB-16-12OR / WD | 1,5 / 16" X12 | G3 / 4" X14 | 22X1.5 | WD-B12 | 23.1 | 16 | 53 | 36 | |
1JB-16-20OR / WD | 1,5 / 16" X12 | G1.1 / 4" X11 | 22X1.5 | WD-B20 | 23.1 | 20 | 61 | 50 | |
1JB-20or / WD | 1.5 / 8" X12 | G1.1 / 4" X11 | 28X1.5 | WD-B20 | 24.3 | 20 | 62 | 50 | |
1JB-20-16OR / WD | 1.5 / 8" X12 | G1" X11 | 28X1.5 | WD-B16 | 24.3 | 18 | 58 | 46 | |
1JB-20-24OR / WD | 1.5 / 8" X12 | G1.1 / 2" X11 | 28X1.5 | WD-B24 | 24.3 | 22 | 64 | 55 | |
1JB-24OR / WD | 1.7 / 8" X12 | G1.1 / 2" X11 | 35X1.5 | WD-B24 | 27,5 | 22 | 67.5 | 55 | |
1JB-24-20OR / WD | 1.7 / 8" X12 | G1.1 / 4" X11 | 35X1.5 | WD-B20 | 27,5 | 20 | 65.5 | 50 | |
1JB-32OR / WD | 2.1 / 2" X12 | G / 2" X11 | 48X2 | WD-B32 | 34 | 20 | 73 | 75 | |
